厦门市哈德沃克电子科技有限公司大量现货代理销售英国Tyco泰科船用火灾报警设备：探测器，报警按钮，探头底座等配件，原厂进口，常年现货。

Tyco 601P-M 516.600.201

850PH, 851PH and 830PH Photo Heat Multi-Sensor Detectors

With its ability to detect a wide range of fires from flaming to smouldering types, the combined optical and heat multi-sensor

detector is the preferred choice for a range of applications including light industrial, retail and office environments.

It operates in a number of approved modes and sensitivities that can be dynamically selected to suit different environmental conditions.

Technical Specification
Detector material: Flame Retardant FR3010 ‘BAYBLEND’
Dimensions: Height 43mm
Dia.109mm
Colour: White
Weight: (Excluding Base)76g.
Voltage: 20 – 40 VDC
Quiescent Current: 380uA
Alarm Current: 3.3mA
Operating Temp: -25 °C to +70 °C
Storage Temp: -40 °C to +80 °C
Relative Humidity: 95% (noncondensing)
Approvals: EN54-5 and EN54- 7,CPD, VdS
Type Approval: CEA4021 851PH MED Approved

Product Codes
516.850.051
850PH Photo Heat Detector with built in line isolator
516.830.051
830PH Photo Heat Detector
516.850.055
851PH Photo-Heat Detector with built in line isolator Marine
